CONSTRUCTION
• LED Linear luminaire for recessed diffused downlight in combination with spots light.
• Construction with Extruded anodised aluminium for better heat sink.
• Strain relief cable clamp.
• Wire from mains up to 2 core X 1.5mm2
• BIS approved Reiz energy saving electronic LED safety driver (BIS NO. R-91000078) is integrated
• REIZ LED driver 24VDC Remote THD<10% PF >0.95 Ripple<10% Surge >3kv
• Active constant current for uniform brightness
• Optional dimmable driver via 0-10V/Dali/Bluetooth
• Available in 1,2,3 Meter Length
• LED CRI >80/90
OPTICAL
Housing: Aluminum Housing
Heat Dispersion: Aluminum Housing die cast
IP Rating: IP 20
LED Type: SMD
Mounting: Torsion Spring
Ambient Temp: -10 to 45 C
Warranty: 5 Years.
ELECTRICAL
Input Wattage: 50W
Input Voltage: 240V AC
Light Output: >110m/W
CCT: 3000/4000/6000K
OPTICS: 25v SYMETRIC
CRI: >80/90
PF: >0.95
THD: <10%
Current Ripple: <10%
Surge Protection: >3kv
