CONSTRUCTION
• Low glare deep recessed down lighter for soft down lighting
• Optical control of 15v to 30v using lens or 70v with diffuser
• Construction in die cast aluminum frame & aluminum extrusion ring
• Double polyester powder coated with high U.V. & corrosion resistance
• Reflector aluminium 99.9% silver bright anodized
• Easy access to driver without removing outer trim
• Fixture holding system using Stainless Steel -304 torsion spring
• Strain relief cable clamp
• Wire for mains supply cable up to 3c×1.5 mm²
• Life time L90 B10 @ 50,000 hrs
• 5 Years warranty
OPTICAL
- LED Type: SMD
- Ambient Temp.: -10v to 45vC
- CCT: 2700/3000/4000/6000K
- CRI: >90, R9>60
- Low Glare: UGR<15
- Optional: Tunable white LED
- Reflector+Lens: Darklight anti-scratch for low glare light with lens
ELECTRICAL
- Input Wattage: 30/40W
- Light Output: >110lm/W
- Surge Protection: 3kv
- Dimming Options: 1-10V, PWM, DALI, DMX, BLUETOOTH
- Flicker Free: <5% Ripple
- Reiz LED Driver: PF>0.95, THD<10%
- Reiz LED Driver BIS No.: R-91000078
