CONSTRUCTION
• Low glare fixed downlight for wet location with tempered safety glass
• Construction in die cast aluminum frame & aluminum extrusion ring
• Double polyester powder coated with high U.V. & corrosion resistance
• Two parts mounting for easy installation and maintenance
• Fixture holding system using Stainless Steel -304 fastening wing
• Strain relief cable clamp with terminal block
• Wire for mains supply cable up to 3c×1.5 mm²
• Life time L90 B10 @ 50,000 hrs
• 5 Years warranty
OPTICAL
- LED Type: COB
- Ambient Temp.: -10v to 45vC
- CCT: 2700/3000/4000/6000K
- CRI: >90, R9>60
- Low Glare: UGR<18
- Optional: Tunable white LED
- Reflector: Darklight anti-scratch for low glare light
ELECTRICAL
- Input Wattage: 8/12/15W
- Light Output: >110lm/W
- Surge Protection: 3kv
- Dimming Options: 1-10V, PWM, DALI, Bluetooth
- Flicker Free: <5% Ripple
- Reiz LED Driver: PF>0.95, THD<10%
- Reiz LED Driver: BIS No.R-91000078
